保温快卷门

● Operating Speed: 0.8m/s ~ 1.6m/s

● Insulation and Energy Saving: The door body is heated on three sides to effectively prevent frost buildup on the sides of the pillars, ensuring smooth operation of the fast door.

● Reliable and Safe: Infrared protection and a soft anti-collision design structure ensure the safety of operation.

● Collision Recovery: If the door curtain is accidentally hit, it will automatically derail. During the upward movement, the door will automatically realign, restoring to its original position without the need for tools.

● Space Saving: Only a small amount of space is required on both sides of the pillars.

● Insulated Curtain: The double-layer cold storage-specific curtain is filled with environmentally friendly polymer insulation material in the middle, improving insulation and energy efficiency.

● Anti-Freeze Structure: The door shakes briefly in short intervals during operation to prevent the curtain from freezing and blocking the door’s movement.

● Pillars: Made of aluminum alloy profiles with an anodized surface treatment, offering good corrosion resistance, durability, and aesthetic appeal.

● Infrared Protection: If there is an obstruction under the fast door, it will remain open. If an object passes during the descent, the door will automatically rise to the open position and then descend again after the obstruction is cleared.

● Control System: Servo motor and servo control system.

◆ Maximum Size: 3350mm × 4600mm

◆ Operating Speed: 0.8m/s ~ 1.6m/s

◆ Insulated Curtain: Double-layer cold storage-specific curtain with environmentally friendly polymer insulation material in the middle

◆ Pillars: Aluminum alloy profiles, anodized surface treatment

◆ Opening Methods: Radar sensing, ground magnetic sensing, remote control sensing, pull cord switch
