硬质快速门

● Fast Passage: The door opens in 5-7 seconds with almost no waiting time.

● Frequent Opening: The fast door motor is designed to handle frequent openings, with up to 1,000 operations per day.

● Sealing: The door panels are equipped with sealing strips, providing excellent sealing performance (tested by national testing centers) to prevent odors from escaping.

● Safety: Features safety bottom edges and safety protection functions to prevent damage to vehicles and personnel.

● Low Failure Rate: The door system operates continuously year-round in waste-to-energy plants, ensuring reliable performance at all times.

● Intelligent Opening: Various intelligent opening options, including Bluetooth, ground magnetic, radar, remote control, and card swiping, allow for automatic operation without manual intervention.

● Insulation: The door is resistant to cold, heavy rain, and strong winds (tested by national testing centers).

● Wind Resistance: The door can withstand winds up to level 12 hurricane strength (tested by national testing centers).

● Anti-Theft: Access control for vehicle entry/exit, preventing unauthorized entry. The door supports manual opening in case of emergency, such as power failure or circuit malfunction, to ensure vehicle passage.

1.Good Air Tightness

Air tightness: 0.62m³/(m²·h), meeting National Standard Level 8 (verified by national testing organizations).

2.Fast Opening and Closing Speed

Opening speed: 0.8m/s ~ 2m/s (adjustable).

Uses the principle of the Archimedean spiral and a double-layer turbine structure to reduce resistance and friction, ensuring smoother high-speed operation.

3.Wind Resistance and Insulation

The door panel uses a patented thermal break design for better insulation.

Insulation rating: National Standard Level 3

Wind resistance: National Standard Level 3 (withstand wind pressure of 0.5kp, relative deflection < L/180).

4.Low Failure Rate

The door can handle thousands of open/close cycles daily and has been proven to operate fault-free for over 1 million cycles.

5.Intelligent and Convenient

Multiple intelligent opening options available: radar, ground magnetic, remote control, Bluetooth, and app-based control.

One-touch start, interlocking, linkage, and custom options available.

6.Customizable Colors

Choose from a variety of colors based on the installation environment.

◆ Maximum Size: 8000mm × 9000mm

◆ Operating Speed: 0.8m/s ~ 2m/s (adjustable, depending on door size)

◆ Wind Resistance: Meets National Standard Level 3 (relative deflection under 0.5kp wind pressure < L/180)

◆ Water Resistance: △p ≥ 700pa, meets National Standard Level 6

◆ Air Tightness: 0.62m³/(m²·h), meets National Standard Level 8

◆ Insulation: K ≤ 0.5W/(m²·K), meets National Standard Level 3
